P4.8mm Indoor Outdoor LED panel by Unilumin

Features

4.8mm pixel pitch, high-resolution outdoor rated LED video panel
1000mm (tall) by 500mm (wide) form factor
Special frame design allows for overhead hanging or ground stacking for maximizing installation flexibility
Magnetic modular design allows quick and easy service
LED modules with dedicated memory stores factory calibration, ensuring color uniformity, optimal picture quality, and simplifies maintenance
Die-cast aluminum housing makes RS series panels the lightest and slimmest in its class without compromising strength
One-man installation possible using the "Quick-Lock" mechanism at the top of each cabinet

Physical Specifications

Pixel Configuration  SMD1921
Pixel Pitch  4.8 mm
Pixel matrix per panel 104x208
Pixel density pixels/sqm 43264
Cabinet Dimensions 500x1000x85
Module Dimensions  250x500
Panel material : Die Casting Aluminum
Cabinet weight lbs per panel  27

Electronic Specifications

Color Grayscale Bit  14
Gray Scale per Color level  16384
Refresh Rate Hz  3840
Signal Transmission Distance   CAT5 cable 100 m

Optical Specifications

Brightness(nits)  4500
Optimal Horizontal Viewing Angle 160
Optimal Vertical Viewing Angle UP 60/down 60
Contrast ratio  6386 to 1

Electrical Specifications

AC Input Voltage(V)  AC: 100V - 240V
AC Input Power Maximum Value 600
AC Input Power Typical Value 200
Storage Temperature(C)  -40-60

Environmental Specifications

Working Temperature (C)  -80
IP rating (Front/Rear) IP65/IP54
Storage Humidity (RH)  10~90 non-condensing
Working Humidity (RH) 10~90 non-condensing
Lifetime Typical Value(hrs)  100000
